02 / PRODUCT RANGE
CLOSED DIEFORGING
Controlled Shapes. High Strength. Repeatability.
We manufacture precision closed die forged components with controlled grain structure, high mechanical properties and excellent dimensional accuracy, suitable for critical industrial applications.
OVERVIEW
Closed die forging is a metal forming process where the heated material is placed in a precision die cavity and shaped by controlled high-pressure forces. This process ensures superior mechanical properties, uniform grain flow, high strength and repeatability, making it ideal for critical components.
We manufacture closed die forged components in a wide range of sizes and material grades for pumps & valves, oil & gas, power, heavy engineering, mining, marine and process industries.
KEY FEATURES
- High strength and improved mechanical properties
- Controlled grain flow and better fatigue life
- Complex shapes with tight dimensional tolerances
- Repeatable and consistent quality
- Lower material waste compared to open processes
- Suitable for high pressure and critical applications
- Heat treatment and machining support
- Manufactured as per customer drawings / standards
- Complete dimensional, NDT and PMI inspection
- Wide range of material grades
SIZE RANGE & CAPACITY
| Max. Forging Weight | Up to 15 Tons per piece |
|---|---|
| Min. Forging Weight | 5 kg (as per component) |
| Max. Diameter (OD) | Up to 3000 mm |
| Max. Height / Length | Up to 1500 mm |
| Process | Closed Die Forging (Drop/Hydraulic) |
| Die Design | As per component & customer requirement |
| Machining Support | VTL, CNC VTL, VMC, Turning, Drilling |
| Heat Treatment | Normalizing, Quenching & Tempering, Stress Relieving (as per grade) |
MANUFACTURING PROCESS
1. Raw Material
Round bar, billet or ingot as per material grade
2. Heating
Controlled heating to required temperature
3. Closed Die Forging
Forming in precision dies using mechanical / hydraulic presses
4. Trimming
Removal of excess material (flash)
5. Heat Treatment
Normalizing / Quenching & Tempering as per grade
6. Machining & Inspection
Final machining, dimensional and NDT inspection
OUR FORGING PRESSES & INFRASTRUCTURE
Hydraulic Closed Die Forging Press
- Capacity: Up to 15 Tons per piece
- Suitable for complex and heavy components
- Precision die forging with high repeatability
Mechanical Closed Die Forging Press
- High tonnage forging press
- Suitable for medium to large components
- Consistent quality and high production rate
MATERIAL GRADES
| Carbon steel | IS 2062 E250, E350, E450; IS 2004; ASTM A36; ASTM A105 |
|---|---|
| Pressure vessel / high tensile | ASTM A516 Grade 70; Fe 410 / Fe 490 where applicable |
| Alloy steel | EN8, EN9, EN19, EN24; SAE 4340; AISI 4140 / 4340 |
| Stainless steel | SS304, SS316, SS316L, SS410 |
| Duplex / super duplex | F51, F53, F55; S31803 / S32750 / S32760 as specified |
| Wear resistant | Hardox 400 / Hardox 450 |
| Other Materials | Other customer-specified grades subject to technical review |
PRODUCT EXAMPLES
APPLICATION INDUSTRIES
Controlled shapes, repeatability and batch production are subject to tooling and customer requirements. Pump components, valve components, engineering components, customized forged parts and near-net-shape components.
